IP 4MP 360° Panoramic Dome

S-4D-4MFE

  • Support IP Filter function
  • Support trigger of Voice Alarm
  • Support Privacy Mask area on Live Video
  • Support Two Way audio
  • Support Flip & Mirror
  • Support RTC (Real Time Clock) function
  • Support Hardware OSD of time display
  • Support 3GPP
Enquiry
Download
Technical Specification
Image Sensor 5 Megapixel CMOS
Sensor Size 4 MP (2032(H) x 1936(V)) / Full HD (1920(H) x 1080(V))
Minimum Illumination Automatic / Night / Outdoor mode
Shutter Speed 752(Horizontal)x 582(Vertical)
Shutter Time 100us – 33333us
AWB Yes
AE Yes
DNR 2D Noise Filter
Video quality setting Yes
Lens Mount Board Lens type
Lens 1.47mm
Angle of View Diagonal 195° / Horizontal 195° / Vertical 195°
Focus Manually
Video Compression Stream 1: H.264 / MJPEG / Stream 2: H.264 / MPEG 4 / MJPEG
Streaming Dual Streaming
Frame Rate Main : 14fps (maximum) for 4 MP (2032x1936) real time for Full HD 1080p(1920x1080), HD-720p(1280x720) Sub: real time for CIF/QCIF when main stream is Full HD and lower, QCIF 20 fps for 3 MP, QCIF 16 fps for 4 MP
Video Output 1port
Audio Input Compression MPEG-1 layer 2, G.711
Audio input 1port
Audio Output Compression ADPCM
Audio Output 1port
Motion Detection Yes
Digital Input 1port
Digital Output 1port
Alarm FTP& E-mail
Ethernet 10/100 Base T Ethernet
Protocol IPv4/IPv6, DHCP, PPPoE, Dynamic DNS, TCP/IP, SMTP, UPnP, HTTP HTTP tunneling(RTSP over HTTP), HTTPs, RTP, RTSP, DNS client, FTP client, NTP
Password Yes
IP Address Filtering Yes
System SoC Embedded ARM-Linux
Frequency 50/60 Hz
Operating Temperature -10° C ~ 50°C
Humidity 10% ~ 90%(no condensation)
Power 12V DC
Power Consumption 4.08 Watt
