| Technical Specification |
| Main Processor |
High performance Dual-core embedded microprocessor |
| Operating System |
Embedded LINUX |
| System Resources |
Pentaplex function: live, recording, playback, backup & remote access |
| Control Mode |
Front panel, USB mouse, IR remote control, Keyboard, Network |
| IP Camera Input |
8ch@D1 / 4ch@720P /2ch@1080P |
| IP Camera Supported |
Provideo, Arecont Vision, AXIS, Canon, Panasonic, SAMSUNG, SANYO, SONY, ONVIF compliant |
| Video Output |
1 HDMI(video & audio), 1 VGA |
| Voice Intercom |
1 channel input, BNC(200-2800mV, 30K Ohms), 1 channel output, BNC(200-3000mV, 5K ) |
| Display Split |
1/4/9 |
| Resolution |
1920x1080, 1280x1024, 1280x720, 1024x768 |
| Tour Display |
Supported |
| Privacy Masking |
4 self-defined four-sided zones for privacy masking for each camera |
| OSD |
Camera title, time, video loss, camera lock, motion detection, recording |
| Compression |
H.264 / MPEG4 |
| Recording Resolution |
1080P(1920× 1080) / 720P(1280× 720) / D1 (704× 576/704× 480) |
| Max Recording Speed |
200/240fps@D1,00fps@720P(BitRate 1Mbps) 50/60fps@1080P Up to 8Mbps |
| Recording Bit Rate |
Up to 8Mbps |
| Recording Quality |
CBR, VBR(1~6 level, level 6 is the best) |
| Recording Mode |
Manual, Schedule, Regular(Continuous), MD(Video detection: Motion detection, Camera blanked, Video loss), Alarm, Stop |
| Recording Priority |
Manual >Alarm >MD >Regular |
| Recording Interval |
1~120 min (default: 60 min) |
| Triggering Events |
Recording, PTZ movement, Tour, Alarm, Email, FTP, Buzzer & Screen tips |
| Motion Detection |
Zones: 396(22× 18), Sensitivity: 1~6 (level 6 is highest) |
| Video Loss & Camera Blank |
Supported |
| Alarm Input |
8 Channel |
| Relay Output |
6 channel |
| Playback Channel |
1/2/4/All |
| Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode |
Flash drive/ USB HDD/ USB CD&DVD-RW / eSATA Device / Built-in SATA burner/ Network download |
| Ethernet |
RJ-45 port (10/100M/1000M) |
| Network Function |
HTTP, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server |
| Max Remote Users |
20 Users simultaneously |
| Remote Operation |
Monitor, PTZ control, Playback, System setting, File download, Log information |
| Hard Disk |
8 SATA ports, 8 HDDs or 6 HDDs + 1 CD/DVD-RW, Up to 24TB |
| eSATA |
4 External SATA ports, up to 12TB |
| Space Occupied |
Max 3.6GB/H per channel |
| HDD Management |
HDD Group,HDD hibernation technology,HDD faulty alarm & Raid(Redundancy) |
| USB Interface |
2 USB2.0 ports, For mouse control & backup |
| RS232 |
keyboard, PC communication |
| RS485 |
PTZ control |
| Power Supply |
AC 100~240 V, 50/60 Hz |
| Power Consumption |
20W(without HDD) |
| Working Environment |
-10 ~+55° C/ 10~90%RH / 86~106kpa |
