Technical Specification | |
CPU | 32-bit processor |
Display | 14.224cm (5.6) TFT-LCD,monitor entrance situation |
Maximum capacity | 9999 gate stations |
Intercom time | max. 2 minutes |
DC voltage | DC15V/DC18V |
Output power | ≥50mW |
Quiescent current | ≤500mA |
Dimension | 340x185x100mm |
Network port | RJ45 |
Network transmission mode | Router or PBX less than 100m, FOT more than 100m |
Transmission range | TCP/IP |
Working humidity | 45%~95% |
Working temperature | - 30°C ~ 55°C |
