| Technical Specification |
| Main Processor |
High performance Dual-core embedded microprocessor |
| Operating System |
Embedded LINUX |
| Control Mode |
Front panel, USB mouse, IR remote control, Keyboard, Network |
| IP Camera Input |
8ch@D1 / 4ch@720P / 2ch@1080P |
| Output |
1 HDMI (video & audio), 1 VGA |
| Display Split |
1/4/9 |
| Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
| Recording Resolution |
1080P |
| Tour Display |
Supported |
| Privacy Masking |
4 self-defined, 4-sided zones for privacy masking for each camera |
| OSD |
Supported |
| Compression |
H.264 / MPEG4 |
| Recording Resolution |
1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480) |
| Max Recording Speed |
100/120fps@D1 / 50fps@720P(BitRate 1Mbps)/ 25/30fps@1080P |
| Recording Bit Rate |
Up to 8Mbps |
| Recording Quality |
CBR, VBR(1~6 level, level 6 is the best) |
| Recording Mode |
Manual, Schedule, Regular(Continuous), MD (Video detection: Motion detection, Camera blanked, Video loss), Alarm, Stop |
| Recording Priority |
Manual >Alarm >MD >Regular |
| Recording Interval |
1~120 min (default: 60 min) |
| Event Triggered Action |
Recording, PTZ movement, Tour, Alarm, Email, FTP, Buzzer & Screen tips |
| Motion Detection |
Zones: 396(22×18), Sensitivity: 1~6 (level 6 is highest) |
| Audio & Alarm Input |
8 Channel |
| Video Input |
1 |
| Relay Output |
3 channel |
| HDD Management |
HDD Group,HDD hibernation technology
HDD faulty alarm & Raid(Redundancy) |
| USB Interface |
1 ports, for mouse control or backup |
| RS232 |
Keyboard, PC communication |
| RS485 |
PTZ control |
| Power Supply |
DC12V/3.3A |
| Power Consumption |
20W(without HDD) |
| Working Environment |
-10°~ +55°C / 10~90% RH / 86~106kpa |
