1080P IP CS Mount Camera

S-2MP-CS

  • Compression: H.264
  • Sensor: 1/2.5”
  • Progressive Scan CMOS
  • Display Resolution: 2MP
  • Illumination: 0.1 Lux / F1.2
  • Lens: C/CS Mount (Optional)
Enquiry
Download
Technical Specification
Sensor 1/2.5” Progressive Scan CMOS
OS Embedded Linux System
Resolution 2MP
Illumination 0.1 LUX / F1.2
Lens C/CS Mount (Optional)
Compression H.264
Synchronization Internal
Electronic Shutter 1/1s~1/10,000s
Image Setting Saturation, brightness, contrast, sharpeness adjustable through client software or web browser
Image Frame Rate 25 / 30FPS
Systems PAL / NTSC
Network Protocols TCP/IP, HTTP, TCP, ICMP, DHCP, UDP, SMTP, FTP, DDNS & RTSP
ICR Function Supported
White Balance Auto
Static IP/DDNS No Static IP, No DDNS Required
Multi Streaming Supported
Password Supported
POE Optional
ONVIF Compliant
Communication Interface RJ45 10/100M
Operating Temperature -20°C ~ +65°C
Humidity ≤95% Non-condensation
Power DC 12V 1A
