| Technical Specification |
| Main Processor |
High Performance Embedded Microprocessor |
| Operation System |
Embedded Linux OS |
| Signal System |
PAL/NTSC |
| System Resource |
Recording, Playback, Remote Access |
| Operation Interface |
Front Touch Panel, Mouse, Remote |
| Video Split |
1/4/9 Split Display |
| Video Playback Resolution |
2 Channel D1 and 6 Channel CIF |
| Bit rate Control |
Dual stream |
| Image Control |
6 Levels |
| Recording Speed |
PAL: 25fps/channel, NTSC: 30fps/channel |
| Video Display Resolution |
PAL: 720X576 fps |
| Motion Detection |
Configurable detection areas |
| Audio Compression |
G.711 |
| Recording mode |
Manual , schedule, sensor, motion detection |
| Recording Prioritys |
Manual > Alarm > Motion Detection > Schedule |
| Playback |
Single Channel, 8 channel Simultaneous |
| Playback Search |
Date, Time, Event, Channel |
| Video Storage |
Local HDD |
| Backup Mode |
USB, DVDRW |
| Video Input |
8 ch. BNC (1.0 p-p, 75 ohm) |
| Video Output |
1 BNC , 1VGA(800x600, 1024x768), Network |
| HDMI Output |
Yes |
| Audio Input |
4 channel RCA |
| Audio Output |
1 channel RCA |
| Ethernet Interface |
RJ45 10M/100M Base-TX |
| PTZ Interface |
1 x RS485 |
| USB Interface |
2 x USB2.0 |
| HDD / SATA Interface |
1 x SATA |
| DVDRW |
Supports USB |
| Back Mode |
USB, DVDRW, Network |
| Protocol |
TCP/IP, DNS, PPOE,DHCP, DDNS,UDP, FTP E-mail, Alarm Server, IP Filter |
| Remote Operations |
Monitor, PTZ Control, Playback, Setting, Video Download, Logs |
| Power Supply |
DC12 10% |
| Power Consumption |
<15W (HDD not included) |
| Working Temperature |
-10°C~ +55°C |
| Working Humidity |
10%~90% RH |
